Returns must be requested within 30 days of purchase. Items must be unused and in original packaging. Prior authorization is required. Change-of-mind or incorrect orders may incur up to a 20% restocking fee.

Find more information in Terms and Conditions here www.shopfittingsstore.com.au/terms-and-conditions-of-use-3

Yes. We ship Australia wide. No matter where you are, we will deliver to your door.

Shopfittings Store ships nationwide and has warehouses in Sydney, Melbourne, and the Gold Coast to ensure prompt delivery to all major capital cities and regional areas.

A French cleat can safely hold anywhere from 30 kg to 180 kg, depending on cleat type, length, wall material, screw quality, and installation. Test data shows:

• 152 mm Type A: 30 kg

• 152 mm Type B: 40 kg

• 1220 mm Type A: 135 kg

• 1220 mm Type B: 180 kg

*Real‑world capacity may be lower if the wall or fasteners are weaker than the cleat itself.

The maximum safe load of a French cleat is determined by four interacting factors

• Wall Material (Critical).
• Screw Type and Installation (Critical)
• Lever Arm Distance (how far the centre of mass projects from the wall)
• Aluminium Strength

Please take time to read product description for more information Split Rail Batten Heavy-Duty 150mm, pair (French Cleat)

Installation Overview

Split batten (French cleat) system is designed for the concealed fixing of panels, signage, or mirrors to walls. It allows for a clean, flush finish with no visible screws, making it easy to both install and remove the panels when needed.

Step-by-Step Installation

1. Separate the Pair: Each set requires two interlocking aluminum pieces—one section mounts to the wall, and the matching section attaches to the back of your panel.

2. Mount the Wall Rail:

• Position one of the rails against your wall at the desired height, ensuring it is perfectly level.
• Secure it into the wall studs or appropriate wall anchors using the provided screws.
• Tip: Make sure the interlocking lip of the rail is facing upward and outward from the wall.

3. Attach the Panel Rail:

• Line up the second rail on the back of the panel or item you want to hang.
• Secure it firmly into place using the included screws.
• Tip: Make sure the interlocking lip on the panel is facing downward and inward so it can drop into the wall mount.

4. Hang the Panel:

• Lift your panel slightly above the wall mount and lower it into place.
• The two low-profile sections will interlock seamlessly, holding the panel securely against the wall with a minimal, concealed gap.
